Clamping and filling profiles

Clamping profiles and filling profiles: How does the system work?

The clamping profile is placed directly on the edge of a sheet metal or component. Its shape and often also a built-in metal core ensure that it sits particularly firmly and does not slip.

The filler profile is then inserted into the clamping profile. This closes the opening, ensures a clean seal and prevents water, dust or air from entering.

The principle can be likened to a zip: neither part alone performs the desired function – only when combined do they create a complete seal.

Special advantages at GfA

To ensure that the combination always fits, our clamping and filling profiles are coordinated with each other. The product description contains clear information such as ‘Matching filling profile: ADTP-XXXX’. This makes selection much easier and prevents profiles from being combined incorrectly.

Materials and Shore hardness

The choice of material determines how flexible, resilient or temperature-resistant a profile is:

PVC (70 ShA): Hard and robust, ideal for applications where the profile must be particularly stable and resistant.
TPE (standard 60 ShA, up to 80 ShA): An elastic material with ‘rubber-like’ properties. It is flexible, UV-resistant and can easily withstand temperature fluctuations. Harder versions (70–80 ShA) are particularly useful for components that are subject to heavy use.

👉 For guidance: the lower the Shore hardness, the softer and more adaptable the profile. Higher values mean greater stability and resistance.

Colours for clamping profiles & filling profiles

Standard colours: Black, window grey
Custom colours: Available in many other RAL colours for orders of 200 m or more – this allows profiles to be visually matched to vehicles or systems.

Typical areas of application

Clamping profiles and filling profiles are used in many areas:

Vehicle construction: e.g. on doors of vans or lorry bodies. The clamping profile fixes securely to the edge, while the filling profile reliably seals the door.
Container and skip construction: Here, the profiles prevent rainwater or dirt from entering the interior.
Machines and systems: Clamping and filling profiles ensure secure connections between sheet metal, covers or flaps.
General edge protection: In addition to sealing, they also protect the edges of the components themselves from damage.

Particularly practical: Different clamping ranges allow both thin sheets and thicker constructions to be clamped securely.

Installation & maintenance

Installation is quick and easy:

Press the clamping profile onto the edge. Thanks to its metal core, it will immediately sit securely in place.
Then insert the appropriate filler profile to close the opening.

Regular visual inspection and cleaning are sufficient to maintain the sealing effect in the long term. If cracks or deformations occur, the profile can be easily replaced.

GfA – Expertise in sealing technology

With over 5,312 profile variants, GfA offers one of the largest ranges of clamping and filling profiles. Precisely manufactured combinations, quality Made in Germany and a wide variety of materials ensure that you will always find the right solution – whether for vehicles, containers, machines or special constructions.

Advantages at a glance:

Precisely coordinated combination of clamping profiles and filling profiles
Materials: PVC (70 ShA) and TPE (60–80 ShA)
Standard colours black and window grey, custom colours available from 200 m
Secure fastening even under vibration and stress
Protection against moisture, dirt and corrosion
Over 5,312 profile variants – the right solution for every requirement
